Company Announcement - Elcometer are pleased to announce the launch of our new range of ultrasonic material thickness gauges, the Elcometer MTG Range. From the entry level MTG2 to the top of the range MTG8, our new range of gauges - combined with the wide range of transducers available - offer the perfect solution for a variety of ultrasonic thickness measurement applications.

Elcometer NDT Model MTG2
• Entry level ultrasonic material thickness gauge
• Single measurement mode; Pulsed-Echo
• Pre-calibrated for measuring on steel only
• Pre-defined measurement rate; 4 readings per second
• Live reading mode; transfer of individual readings to a PC or similar device via USB

Elcometer NDT Model MTG4; All the features of the MTG2 plus

• Additional measurement mode; Echo-Echo ThruPaint™
• Choice of calibration methods; 1 Point, Material and Factory Calibration.

Elcometer NDT Model MTG6; All the features of the MTG2 & MTG4 plus
• Additional measurement mode; Velocity
• Additional calibration methods; 2 Point, Velocity & Thickness Set.
• User selectable reading resolution; 0.1mm or 0.01mm
• User selectable measurement rate; 4, 8 or 16 readings per second
• User definable display; Readings, Selected Statistics, Bar Graph & Run Chart
• Sequential Batching
• Gauge memory; a single sequential batch of up to 1,500 readings
• USB and Bluetooth® data output to ElcoMaster™ and ElcoMaster™ Mobile Apps for Android™ and iOS Devices.

Elcometer NDT Model MTG8; All the features of the MTG2, MTG4 & MTG6 plus
• Three user programmable calibration memories
• Extra display options; Readings & Differential and B-Scan
• Grid Batching
• Gauge memory; up to 100,000 readings in 1,000 sequential or grid batches
• User definable upper and lower limits with audible & visual pass/fail warnings


Elcometer MTG Transducers

A wide range of potted, right angle, dual element transducers is available suitable for measuring various materials.  Elcometer MTG transducers are ‘intelligent’ transducers and when connected, will be automatically identified by the gauge.

Non Elcometer MTG transducers and transducers with lemo connectors from other manufacturers, are also compatible with the MTG product range when used together with the optional dual element transducer adaptor, which is simply plugged into the transducer connection point at the base of the gauge prior to connecting the transducer.

For more information please contact BAMR on 021 683 2100 or sales@bamr.co.za – www.bamr.co.za
