Cadia expansion project, Australia
Name of the Project
Cadia expansion project.
Location
New South Wales, Australia.
Project Owner/s
Newcrest Mining.
Project Description
The Newcrest board has approved the first of two stages in the Cadia expansion project.
The first stage comprises the start of the next cave development (PC2-3) and an increase in the nameplate capacity of the process plant to 33-million tonnes a year.
The feasibility study for PC2-3 recommends several mine design changes from the 2018 prefeasibility study, including:
∙ the relocation of the crushing and materials infrastructure to the eastern side of the footprint, which has lower exposure to potential seismic activity, thereby enhancing the safety of personnel and reliability of the operation.
∙ an increase in the number of extraction drives (from nine to 14).
∙ a reduction in operational constraints, which is expected to increase production rates from 13-million tonnes a year to 15-million tonnes a year.
The plant expansion includes upgrades to concentrator circuits 1 and 2, the addition of a coarse-ore flotation circuit and ancillary upgrades to equipment.
Concentrator 1 is currently constrained by secondary crushing motor power and semiautogemous grinding (SAG) motor power. The plant expansion works in Stage 1 of the Cadia expansion project aim to increase Concentrator 1 throughput in stages from 23-million tonnes a year up to 25-million tonnes a year through conveyor upgrades and installation of a new secondary crushing circuit, which together, are expected to increase throughput by one-million tonnes a year). The works also aim to replace a SAG mill motor to increase power from 20 MW to 22 MW, with an expected increase in throughput of one-million tonnes a year.
The Cadia expansion feasibility study recommends increasing the grind size, which allows a further one-million tonnes a year in expected throughput of Concentrator 1 to a total rate of 26-million tonnes a year. Together with the currently installed capacity of Concentrator 2 of seven-million tonnes a year, this provides Cadia with 33-million tonnes a year of milling capacity.
The second stage, which is in feasibility study, is focused on a further increase in processing capacity to 35-million tonnes a year and recovery rate improvement projects targeted for completion in 2022, ahead of the completion of the cave development.
Average yearly gold production is estimated at 381000 oz and average yearly copper production at 77000 t over the project’s 45-year mine life.
Potential Job Creation
Not stated.
Net Present Value/Internal Rate of Return
The net present value for both stages is estimated at $1.17-billion and an internal rate of return of 21.5%, with a payback of
7.6 years.
Capital Expenditure
Stage 1 is estimated at $685-million and Stage 2 at $180-million.
Planned Start/End Date
The PC2-3 mine is targeting first production in the 2023 financial year.
Latest Developments
Newcrest Mining approved the project in October 2019.
Key Contracts and Suppliers
None stated.
On Budget and on Time?
Too early to state.
Contact Details for Project Information
Newcrest Mining, tel +61 3 9522 5333 or email corporateaffairs@newcrest.com.au.
